Factory Price 10W 300-350lm Zoomable LED Shapeable Commercial Track Lighting
The T1003K-3836B is a 10W LED contour spotlight from Kingfisher 2 series featuring a 15°-36° zoom lens for ultra-high-definition projection with ≤0.6% TV distortion. It delivers 300-350LM output with Ra≥97 color accuracy and supports 2700K/3000K/4000K CCT options. The compact magnetic design (Ø38mm radiator, 0.36Kg) enables 90° vertical and 355° horizontal rotation for precise positioning. Compatible with smart controls (DALI, Zigbee, Bluetooth), it's ideal for museums, retail displays, and architectural lighting, offering millimeter-level spot shaping with 11-lens optics for uniform illumination. The anti-glare design (UGR<19) ensures comfortable viewing in premium commercial applications.
| Item no. | T1003K - 3836B |
| Power | 10W |
| Luminous Flux (3000K) | 300-350LM |
| Beam Angle (Lens Model) | Zoom 15-36° (3836B) |
| Ra | 97 |
| Color of housing | Black, White |
| Dimension (mm) | ¢38*H178.5 (¢38 lens) |
| Track type | 4 wires |
Key Features
• Variable Zoom Optics (15°-36°) - Adjustable beam angle provides versatile lighting control from spot to flood
• High-Precision Projection (≤0.6% Distortion) - Ultra-sharp imaging with minimal distortion for detailed projections
• Professional Color Rendering (Ra≥97) - Exceptional color accuracy for true-to-life illumination
• Smart Lighting Compatibility - Seamless integration with DALI, Zigbee, and Bluetooth systems
• Flexible Rotation & Compact Design - 90° vertical and 355° horizontal tilt with magnetic mounting
• Anti-Glare Performance (UGR<19) - Low unified glare rating ensures comfortable viewing
Technical Advantages
Cold Forging Integrated Radiator Design
A radiator made of 1070# pure aluminum molded by pressure. High thermal conductivity (226W/m.K), low-temperature differences, low light failure, and long service life.
360° Manual Rotation Design
Loosen the manual screw and turn the lens to achieve 360° spot rotation adjustment. Designed to solve the 360° rotation of projection and light spot.
High-Definition Optical Lens Design
Formed by multiple high-definition coated optical lenses. Features high luminous efficiency, high spot uniformity, minor distortion, extensive linear zoom range, and good spot cut-off line. Specially designed for COB light sources.
Optical-Grade Variable Aperture Design
An optical diaphragm made of high-precision special material with no blurring and freezing. Manual insertion and removal of the light cutting device can freely change the shape of the spot.
Multi-Layer Dry Damping Design
A focusing device not requiring lubricating oil with silky feel. Stable, reliable, wear-resistant, resistant to high temperatures, and doesn't wear off after extended use. Rotating the device changes spot sharpness.
Linear Zoom Enhancement
Short stroke, considerable focal length, high short-focus and long-focus recognition. Linear zoom is enhanced and more convenient. Rotate the device to adjust spot size.
Product Parameters
Application Scenarios
• Museum & Art Gallery Lighting - Perfect for highlighting artwork with precise, high-CRI illumination
• Retail & Luxury Displays - Ideal for accent lighting in boutiques with sharp, adjustable beams
• Hotel & Restaurant Ambiance - Enhances interior design with warm-to-neutral white tuning
• Architectural & Event Lighting - Used for dynamic gobo projections and framing architectural features
• Home Decorative Lighting - Adds high-end touch to residential spaces for wall-washing and artwork illumination
• Machine Vision & Studio Lighting - Delivers distortion-free, uniform light for precision applications
Packaging & Shipping
Certifications
Frequently Asked Questions
Q1: What do you sell?
A1: We provide good quality floodlights, high bay lights, explosion proof lights, tri-proof lights, downlights, and other lighting products with responsible services and reliable after-sales warranty.
Q2: Is it OK to print my logo on LED light product?
A2: Yes. We provide ODM and OEM services. Please inform us formally before production and confirm the design based on our sample.
Q3: How to deal with faulty products?
A3: During the guarantee period, we will send new lights with new orders for small quantities. For defective batch products, we will repair and resend them or discuss solutions including recall based on the situation.
Q4: Can I have a sample order for LED light?
A4: Yes, we welcome sample orders to test and check quality. One sample or mixed samples are acceptable.
Q5: How long to ship the goods after placing an order?
A5: Usually 7 days for sample or small orders, 15 working days for bulk orders, depending on order quantity.
